Oracle ZS5 SERIES User Manual

Maximum Disk Shelves per Controller Configuration
Controller
Configuration
All DE3 Disk
Shelves
All DE2 Disk
Shelves
DE3 and DE2 Disk
Shelves
DE2 and Sun Disk
Shelves
ZS5-2 with SAS-3
4x4 port HBAs
Yes No No No
ZS5-2 with SAS-2
4x4 port HBAs
No Yes No No
ZS4-4 with SAS-2
4x4 port HBAs
No Yes No No
ZS3-4 with SAS-2
4x4 port HBAs
No Yes No Yes
ZS3-2 with SAS-2
4x4 port HBAs
No Yes No Yes
7420 with SAS-2
4x4 port HBAs
No Yes No Yes
7420 with SAS-2
2x4 port HBAs
No Yes No No
7320 with SAS-2
4x4 port HBAs
No Yes No Yes
7320 with SAS-2
2x4 port HBAs
No Yes No No
7120 with SAS-2
2x4 port HBAs
No Yes No Yes
Maximum Disk Shelves per Controller Configuration
When determining how many disk shelves a controller configuration supports, it is important
to remember that each disk shelf chain can support up to six disk shelves, and some controller
configurations are limited to a specific number of total disk shelves. The following table details
the number of supported disk shelf chains per HBA type.
TABLE 3
Supported Disk Shelf Chains per HBA
HBA Type Number of Disk Shelf Chains per HBA
SAS-3 4x4 port 2
SAS-2 4x4 port 2
SAS-2 2x4 port 1
Controllers cannot simultaneously use 2x4 port SAS-2 HBAs and 4x4 port SAS-2 HBAs. In
addition, only DE3-24 disk shelves can be connected to SAS-3 HBAs, and DE3-24 disk shelves
cannot be used in the same system as DE2-24 disk shelves or Sun Disk Shelves.
Installation Prerequisites and Hardware Overviews 17
