Overview of 7120 Controller
■
Ethernet Ports - There are four RJ-45 Gigabit Ethernet ports (NET 0, NET 1, NET 2,
NET 3) located on the motherboard that operate at 10/100/1000 Mbit/sec. These network
interfaces must be configured before use.
■
Network Management Port - The network management connector (NET MGT) is an RJ-
45 port and provides an alternate terminal interface to the SP console.
■
Serial Management Port - The serial management connector (SER MGT) is an RJ-45 port
and provides a terminal connection to the SP console.
72 Oracle ZFS Storage Appliance Installation Guide • December 2016
