Overview of 7420 Controller
For information about supported HDDs and SSDs, see the Oracle Systems Handbook.
FIGURE 37
SAS-2 and SATA Boot Drive LEDs
Figure Legend
1 Ready to remove (blue) 2 Service action required (amber) 3 OK/Activity (green)
7420 Rear Panel Components
The following graphic shows the rear panel of the controller. Base configuration HBAs are not
depicted in this illustration.
For information about PCIe cards, see “7420 PCIe I/O Cards” in Oracle ZFS Storage Appliance
Customer Service Manual.
64 Oracle ZFS Storage Appliance Installation Guide • December 2016
