Overview of ZS5-4 Controller
■
Up to 24 3.5" SAS-3 HDDs, SSDs. For information about supported HDDs and SSDs, see
the Oracle Systems Handbook.
Oracle Storage Drive Enclosure DE2-24P Components
■
Drive Enclosure DE2-24P Base Chassis
■
Filler Panel, Drive Enclosure DE2-24P
■
Up to 24 2.5" SAS-2 or SAS-3 HDDs, SSDs. For information about supported HDDs and
SSDs, see the Oracle Systems Handbook.
Oracle Storage Drive Enclosure DE2-24C Components
■
Drive Enclosure DE2-24C Base Chassis
■
Filler Panel, Drive Enclosure DE2-24C
■
Up to 24 3.5" SAS-2 or SAS-3 HDDs, SSDs. For information about supported HDDs and
SSDs, see the Oracle Systems Handbook.
Sun Disk Shelf (DS2) Components
■
Sun Disk Shelf (DS2) 24x3.5" SAS-2
■
Sun Disk Shelf (DS2) 24x3.5", LOGFiller
■
Disk Shelf Rail Kit
■
Up to 24 3.5" SAS-2 HDDs, SSDs. For information about supported HDDs and SSDs, see
the Oracle Systems Handbook.
Overview of ZS5-4 Controller
This section provides an overview of the Oracle ZFS Storage ZS5-4 controller. For installation
instructions, refer to “Installing a ZS5-4 Controller” on page 99. For service instructions,
refer to “Servicing the ZS5-4 Controller” in Oracle ZFS Storage Appliance Customer Service
Manual.
Refer to http://oracle.com/zfsstorage for the most recent component specification.
ZS5-4 Physical Specifications
The ZS5-4 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 5.1 in./129.9 mm Depth 28.8 in./732.0 mm
Width 17.2 in./436.5 mm Weight (Maximum) 88 lb./40 kg
38 Oracle ZFS Storage Appliance Installation Guide • December 2016
