Overview of ZS3-4 Controller
Overview of ZS3-4 Controller
This section provides an overview of the Oracle ZFS Storage ZS3-4 controller. For installation
instructions, refer to “Installing a ZS4-4 or ZS3-4 Controller” on page 127. For service
instructions, refer to “Servicing the ZS3-4 Controller” in Oracle ZFS Storage Appliance
Customer Service Manual.
ZS3-4 Electrical Specifications
The following list shows the electrical specifications for the ZS3-4 controller.
Note - The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Input
■
Nominal frequencies: 50/60Hz
■
AC operating range: 200-240 VAC
■
Maximum current AC RMS: 12A @ 200 VAC
Power Dissipation
■
Max power consumption: 1800 W
■
Max heat output: 6143 BTU/hr
■
Volt-Ampere rating: 1837 VA @ 240 VAC, 0.98 P.F.
ZS3-4 Configuration Options
The ZS3-4 controller can be configured as a single controller or two controllers to create a high-
availability cluster configuration. The following table describes the configuration options:
CPU Memory Readzilla Boot Drive HBA
4x10-core, 2.40GHz 1TB (16GB DIMMs) Four SSDs Two HDDs 4-port (4X4) SAS-2
6Gb/s external
Refer to http://oracle.com/zfsstorage for the most recent component specification.
Installation Prerequisites and Hardware Overviews 51
