Overview of ZS3-2 Controller
■
Max power consumption: 890 W max
■
Max heat output: 3026 BTU/hr
■
Volt-Ampere rating: 908 VA @ 240 VAC, 0.98P.F.
ZS3-2 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 7779, the workplace-dependent noise level
of this product is less than 70 db (A).
ZS3-2 Configuration Options
The ZS3-2 controller is an enterprise-class, rackmount x86 system powered by the Intel Xeon
processor. It provides high performance and room for growth with expandable PCIe slots and
16 DIMM slots in a compact 2U footprint. The following table describes the configuration
options.
CPU Memory Readzilla Boot Drive PCIe Slots HBA
2x8-core, 2.1
GHz
256GB
16x16GB
512GB
16x32GB
1-4 SSDs Two 2.5-inch
SAS HDDs
Two dedicated;
four available
4-port (4x4)
SAS-2 6Gb/s
external
Refer to http://oracle.com/zfsstorage for the most recent component specification.
ZS3-2 Front Panel Components
The ZS3-2 controller drive slots and front panel components are shown in the following figure.
56 Oracle ZFS Storage Appliance Installation Guide • December 2016
