Overview of ZS5-4 Controller
ZS5-4 Electrical Specifications
The ZS5-4 controller has two hot-swappable rear accessible power supplies with N+N
redundancy. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 200-240 VAC
Rated input current 10 A @ 200 to 240 VAC
Maximum power consumption 200W
Maximum heat output 6824 BTU/hr
ZS5-4 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 9296, the workplace-dependent noise level
of this product is less than 75 dBA (bystander position, max. ambient).
ZS5-4 Configuration Options
The ZS5-4 incorporates one or two controllers and one to forty-eight disk shelves. Each
controller has eleven PCle Gen3 slots. Each controller includes six 2.5'' disk slots that
accommodate two system disks. Read cache devices are installed in disk shelves; therefore,
the remaining four disk slots have permanent filler panels. The following table describes the
configuration options.
CPU Memory System Disks PCIe Slots HBA
4x18-core, 2.6
GHz
1536 GB 2x2.5'' SAS-3 Four dedicated;
seven available
4-port (4x4) SAS-3 12 Gb/s
external
4-port (4x4) SAS-2 6 Gb/s
external
The most recent component specification is located at https://www.oracle.com/storage/
nas/index.html.
Installation Prerequisites and Hardware Overviews 39
