Connecting Disk Shelf Cables
Connecting Disk Shelf Cables
Use the following procedure to connect the cables between storage controller(s) and disk
shelves.
Caution - Do not connect the power cables until instructed to do so in “Powering On the
Appliance” on page 177.
The cabling configuration for your appliance depends on the number and type of controllers and
disk shelves, as well as the number of host bus adapters (HBAs) in your system. Disk shelves
attach to other disk shelves with daisy-chained serial attached SCSI (SAS) cables. Controllers
attach to each disk shelf chain with a longer SAS cable connected via HBAs located in specified
PCIe slots of the controllers. Clustered controllers are attached via three Ethernet cables that
provide redundant communication channels: two serial links and an Ethernet link. The cabling
methodology designed for the appliance includes bottom-to-top cabling for easier growth with
optimum safety, strategic slot placement for optimum load distribution and performance, and
interface redundancy for clustered controllers, ensuring no single point of failure.
1.
Locate the appropriate cabling configuration for your system in “Getting Started
with Cabling” in Oracle ZFS Storage Appliance Cabling Guide.
■
“Cabling DE3-24 Disk Shelves to 4X4 Port SAS-3 HBAs” in Oracle ZFS Storage
Appliance Cabling Guide
■
“Cabling DE2-24 Disk Shelves to 4X4 Port SAS-2 HBAs” in Oracle ZFS Storage
Appliance Cabling Guide
■
“Cabling DE2-24 Disk Shelves to 2X4 Port SAS-2 HBAs” in Oracle ZFS Storage
Appliance Cabling Guide
■
“Cabling Sun Disk Shelves” in Oracle ZFS Storage Appliance Cabling Guide
■
“Cabling Mixed DE2-24 and Sun Disk Shelves” in Oracle ZFS Storage Appliance Cabling
Guide
2.
Connect cables between disk shelves and between storage controller(s) and
disk shelves.
If clustered controllers, be sure to connect the cluster cables as described in “Connecting
Cluster Cables” on page 172.
Example 5
Disk Shelf Cabling Example
The following illustration shows the cable connections for two clustered Oracle ZFS Storage
ZS4-4 controllers and eight DE2-24C disk shelves. The controllers, as recommended, are
located in the middle of the cabinet.
Cabling the Appliance 175
