Oracle ZS5 SERIES User Manual

Connecting Cluster Cables
ZS4-4 Cluster Cabling
Note - The cluster card for ZS3-4 and 7420 is installed in the Cluster slot, as described in the
hardware overview for each controller in Oracle ZFS Storage Appliance Customer Service
Manual.
The following figure shows cluster cabling between two ZS3-2 controllers.
ZS3-2 Cluster Cabling
174 Oracle ZFS Storage Appliance Installation Guide • December 2016
