Installing a DE2-24C Disk Shelf
6.
Install one long patchlock screw per rail to secure the rear of the shelf to the rear
of the rack. If the screw cannot be inserted, the shelf might not be fully seated
within the rails.
7.
Remove the front side caps, install one screw into each front side, and replace
the caps.
Installing a DE2-24C Disk Shelf
Use the following procedure to install an Oracle Storage Drive Enclosure DE2-24C, which
requires four rack units (RU), or twelve rack holes, of vertical space in the cabinet.
88 Oracle ZFS Storage Appliance Installation Guide • December 2016
