Overview of 7420 Controller
Figure Legend
4 Connector B 5 Connector C 6 Connector D
7 Slide-rail latching bracket (used
with connector D)
8 Rear slide bar 9 Cable covers
Overview of 7420 Controller
This section provides an overview of the Oracle ZFS Storage 7420 controller. For installation
instructions, refer to “Installing a 7x20 Controller” on page 155. For service instructions,
refer to “Servicing the 7420 or 7320 Controller” in Oracle ZFS Storage Appliance Customer
Service Manual.
7420 Physical Specifications
The 7420 controller 3U chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 13.3 cm/5.25 in Depth 70.6 cm/27.8 in
Width 43.7 cm/17.19 in Weight 16.36 kg/96 lbs
7420 Electrical Specifications
The following list shows the electrical specifications for the 7420 controller.
Note - The power dissipation numbers listed are the maximum rated for the power supply and
are not a rating of the actual power consumption of the appliance.
Input
■
Nominal frequencies: 50/60Hz
■
AC operating range: 100-127 VAC for 2 CPUs and 200-240 VAC for 2 or 4 CPUs
■
Maximum current AC RMS: 12A @ 100 VAC / 12A @ 200 VAC
Power Dissipation
Installation Prerequisites and Hardware Overviews 61
