Overview of 7320 Controller
7320 Electrical Specifications
The following list shows the electrical specifications for the 7320 controller.
Note - The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors, which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz
■
Nominal voltage range: 100-120/200-240 VAC
■
Maximum current AC RMS: 9.0 amps Max
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.6A
■
+12 VDC: 62.3A
Power dissipation
■
Max power consumption: 873 W
■
Max heat output: 2977 BTU/hr
■
Volt-Ampere rating: 891 VA @ 240 VAC, 0.98P.F.
7320 Base Configurations
The 7320 controller base configuration options are:
■
Single or cluster
■
24GB or 96GB RAM
■
2x2.4GHz Quad-Core processors
■
One external SAS HBA
■
Four 10/100/1000 Ethernet ports
