Connecting Disk Shelf Cables
For cabling diagrams of specific configurations, refer to “Getting Started with Cabling” in
Oracle ZFS Storage Appliance Cabling Guide.
Callout Description Callout Description
1 Shelf 8 (RU 35-38) 6 Controller 2 (RU 17-19)
2 Shelf 7 (RU 31-34) 7 Shelf 4 (RU 13-16)
3 Shelf 6 (RU 27-30) 8 Shelf 3 (RU 9-12)
4 Shelf 5 (RU 23-26) 9 Shelf 2 (RU 5-8)
5 Controller 1 (RU 20-22) 10 Shelf 1 (RU 1-4)
176 Oracle ZFS Storage Appliance Installation Guide • December 2016
