Overview of Disk Shelves
FIGURE 5
DE3-24C Status Indicators (Front View)
Figure Legend
1 Locate indicator 2 Service required indicator 3 OK indicator
4 Power supply fault indicator 5 SAS I/O Module fault indicator 6 Ready-to-remove indicator
7 Drive service required indicator 8 Power/Activity indicator
24 Oracle ZFS Storage Appliance Installation Guide • December 2016
