Overview of Disk Shelves
FIGURE 7
DE3 I/O Module Indicators
Figure Legend
1 For Oracle service only 2 Locate indicator 3 Service required indicator
4 OK indicator 5 SAS-3 Port 0 6 SAS-3 Port 1
7 SAS-3 Port 2 8 SAS-3 Port 3 9 Host port activity indicator
10 Power/Activity indicator 11 Drive service required indicator 12 Ready-to-remove indicator
13 For Oracle service only
The DE3-24C and DE3-24P disk shelves use the same I/O Module.
26 Oracle ZFS Storage Appliance Installation Guide • December 2016
