OPERATION ORBAN Model 8400
URBAN: There are two URBAN (Rap) presets: HEAVY and LIGHT. These are similar to
ROCK-MEDIUM and ROCK-OPEN but with a different bass sound. They use the 3-pole
(18 dB/octave) shape on the bass equalizer.
URBAN-HEAVY is appropriate for Urban,
Rap, Hip-Hop, Black, R&B, Dance and other similar formats.
URBAN-LIGHT is appro-
priate for light R&B formats. Highly competitive Urban stations might also use
LOUD-
HOT+BASS
or LOUD+SLAM, modified versions of LOUD-HOT that maximize bass
punch.
Equalizer Controls
The table summarizes the equalization controls available for the Five-Band structure.
1
Equalizer Controls
Group Basic/Intermediate
Name
Advanced Name Range
Bass
Shelf
Bass Shelf Hinge
Frequency
Bass Freq 80 … 500 Hz
Bass Shelf Gain Bass Gain 0 … 12 dB
Bass Shelf Slope Bass Slope 6,12,18 dB/Oct
Low
Low Frequency Low Freq 20 ... 500 Hz
Low Gain Low Gain –10.0 … +10.0 dB
Low Width Low Width 0.8 ... 4 octaves
Mid
Mid Frequency Mid Freq 250 ... 6000 Hz
Mid Gain Mid Gain –10.0 … +10.0 dB
Mid Width Mid Width 0.8 ... 4 octaves
High
High Frequency High Freq 1.0 … 15.0 kHz
High Gain High Gain –10.0 … +10.0 dB
High Width High Width 0.8 ... 4 octaves
--- Brilliance Brilliance 0.0 … +6.0 dB
--- DJ Bass DJ Bass off, 0 … 10
--- HF Enhancement HF Enhance 0 … 15
Table 3-2: Five-Band Equalization Controls
Most equalization controls are common to both the Two-Band and Five-Band structures.
The equalizer is located between the AGC and multiband compressor sections of both
structures.
Any equalization that you set will be automatically stored in any User Preset that you
create and save. For example, you can use a User Preset to combine an unmodified Fac-
1
These EQ controls are available in Basic Modify, Intermediate Modify and Advanced Modify
screens. However, some of the control names have abbreviated names in the Advanced Modify
screen, as noted in the table.
