Orban OPTIMOD 8400 - Input;Output Circuit Board

6-16
TECHNICAL DATA Orban Model 8400
29527.000.01 INDUCTOR, FIT44-4 L46
15025.000.01 TRANSTOR, MTG, KIT TO 220
15028.003.01 INSULATOR, 8400 P/S
24308.901.01 IC, LINEAR, DC REG, 5V NEG U4
24319.000.01 IC, DC NEGATIVE VOLTAGE REGULATOR U2
24325.005.01 IC, VOLT REGULATOR, "T", POS, 5 VOLT U3
24325.015.01 IC, VOLT REGULATOR, "T", POS, 15 VOLT U1
27496.000.01 CONNECTOR, RCPT, 3 WIRE, CLOSED END
28004.150.01 FUSE, 3AG, SLOBLO, 1/2 AMP
28112.003.01 KNOB, FUSE, DOM, GRY, FOR 281
29265.000.01 FAN, 12V
29267.000.01 FILTER FAN GUARD 80MM
51001.000.01 HEAT SINK INSULATOR, 8400
57129.000.01 BRACKET, POWER SUPPLY FAN
57130.000.01 BRACKET, POWER SUPPLY HEATSINK
57131.000.01 HEATSINK
57128.000.02 PANEL, FAN
55041.000.02 TRANSFORMER TOROID 8400 115/230 T1
Input/Output Circuit Board
PART # DESCRIPTION COMPONENT IDENTIFIER
27053.001.01 CONNECTOR, XLR, HOUSING, MALE J201 J202 J502
27054.001.01 CONNECTOR, XLR, FEMALE, HSNG J100 J103 J500 J501
20041.100.01 RESISTOR, MF, 1/8W, 1%, 1.00 K ohm R100 R107 R115 R120
20058.187.01 RESISTOR, MF, 1/8W, 0.1%, 1.87K R301 R316
20058.205.01 RESISTOR, 1/8W.1%, 2.05K R302 R319
20121.100.01 RESISTOR, RF, 1/8W, 1%, 10 ohm R154 R200 R232 R522
20122.110.01 RESISTOR, TF, 1/8W, 1%, 110 ohm R500 R514 R517 R238 R330
20123.100.01 RESISTOR, TF, 1/8W, 1%, 1k R304 R317 R521 R600 R601
20123.150.01 RESISTOR, TF, 1.8W, 1%, SURFACE MOUNT 1 R131 R134 R140 R141 R144
R146
20123.499.01 RESISTOR, TF, 1/8W, 1%, 4.99K R101 R103 R105 R108 R116
R118 R121 R124
20124.100.01 RESISTOR, TF, 1/8W, 1%, SURFACE MOUNT 1 R110 R125 R237 R519 R243
R244
20126.100.01 RESISTOR, TF, 1/8W, 1%, 1.00M R142 R152 R225 R231 R306
R322
20129.150.01 RESISTOR, 1/8W, 1%, 150 ohm R138 R151 R235 R236
20129.249.01 RESISTOR, 1/8W, 1%, 249 ohm R137 R139 R149 R150 R155
20129.768.01 RESISTOR, 1/8W, 1%, 768 ohm R111 R126
20130.162.01 RESISTOR, 1/8W, 1%, 1.62K R132 R153 R156 R157
20130.178.01 RESISTOR, 1/8W, 1%, 1.78K R502 R510 R515
20130.210.01 RESISTOR, 1/8W, 1%, 2.10K R112 R127
20130.221.01 RESISTOR, 2.21K R305 R318
20130.249.01 RESISTOR, 1/8W, 1%, 2.49K R300 R315
20130.348.01 RESISTOR, 1/8W, 1%, 3.48K R204 R210 R217 R220
20130.562.01 RESISTOR, 1/8W, 1%, 5.62K R113 R128
20130.845.01 RESISTOR, 1/8W, 1%, 8.45K R201 R202 R205 R207 R208
R211 R212 R214 R215 R218
20131.113.01 RESISTOR, 1/8W, 1%, 11.3K R206 R219 R233 R234
20131.143.01 RESISTOR, 1/8W, 1%, 14.3K R221 R224 R227 R230
20131.147.01 RESISTOR, 1/8W, 1%, 14.7K R114 R129
