OPTIMOD-FM TECHNICAL DATA
6-15
field-replaceable. We have endeavored to include all field-replaceable parts in this list.
However, some non-field-replaceable parts have been omitted.
See the following assembly drawings for locations of components.
Obtaining Spare Parts
Special or subtle characteristics of certain components are exploited to produce an ele-
gant design at a reasonable cost. It is therefore unwise to make substitutions for listed
parts. Consult the factory if the listing of a part includes the note “selected” or “realign-
ment required.”
Orban normally maintains an inventory of tested, exact replacement parts that can be
supplied quickly at nominal cost. Standardized spare parts kits are also available. When
ordering parts from the factory, please have available the following information about the
parts you want:
Orban part number
Reference designator (e.g., C3, R78, IC14)
Brief description of part
Model, serial, and “M” (if any) number of unit ⎯ see rear-panel label
To facilitate future maintenance, parts for this unit have been chosen from the catalogs of
well-known manufacturers whenever possible. Most of these manufacturers have exten-
sive worldwide distribution and may be contacted through their web sites.
Power Supply
PART # DESCRIPTION COMPONENT IDENTIFIER
21123.410.01 CAPACITOR, RADIAL LEADS, 0.1UF, 50V, 20% C10 C11 C12 C4 C5 C6 C7 C8 C9
21209.822.01 CAPACITOR, RADIAL LEADS, 2200uF, 50/63V C1 C2 C3
21227.710.01 CAPACITOR, RADIAL LEADS, 100uF 16V HFS C50
21227.747.01 CAPACITOR, RADIAL LEADS, 470uF 16V HFS C52 C53
21229.610.01 CAPACITOR, RADIAL LEADS, 10uF 35V HFS C13 C14 C15 C16
21230.710.01 CAPACITOR, RADIAL LEADS, 100uF 50V HFS C19
21256.000.01 CAPACITOR, RADIAL LEADS, 1000uF, 35V, 20% C17
21258.910.01 CAPACITOR, ALUMINUM ELECTROLYTIC 10,000uF,
25V
C18
22083.022.01 DIODE, SURGE SUPPRESSOR, 22 VOLT CR10 CR11 CR12 CR13 CR14
22083.033.01 DIODE, SURGE SUPPRESSOR, 33 VOLT CR6 CR7
22083.068.01 DIODE, SURGE SUPPRESSOR, 6.8 VOLT CR15 CR16 D1
22208.040.01 DIODE, SCHOTTKY, 31DQ04, 3.3 D2
22303.000.01 DIODE, RECTIFIER, 100V, 4 AMP CR8 CR9
22305.000.01 DIODE, BRIDGE GBPC2506W CR1
22500.271.01 ZENER, TRANSSORB, VARISTOR V1 V2
24323.000.01 IC, SIMPLE SWITCH, 0 TO 220 U38
26143.000.01 SW, SLIDE, VOLT, 115/230 S2
26146.000.01 SW, SLIDE, SPDT, VERT MOUNT
28112.005.01 BODY, FUSEHOLDER, PC MNT FH1
29262.000.01 LINE FILTER, PC MNT, 1A J1
29504.150.01 INDUCTOR, 2A, PE53113 L45
