2-52
INSTALLATION ORBAN Model 8400
Input: Digital: selects the digital input. No J.17 de-emphasis is applied to
the digital input.
Input: Digital+J.17: selects the digital input and applies J.17 de-emphasis to
the digital input.
Bypass: switches the Bypass Test Mode on the air.
Tone: switches the Tone Test Mode preset on the air.
Exit Test: If a test preset is switched on the air,
exit test reverts to the previ-
ous processing preset.
Stereo: switches the 8400’s stereo encoder on.
Mono From Left, Mono From Right, or Mono From Sum: switches the
8400’s stereo encoder off, using the Left, Right, or Sum (L+R) respectively,
as the program source.
Modulation Reduction 1, or Modulation Reduction 2: reduces the pro-
gram modulation by the percentage programmed in the Input/Output screen.
When voltage is removed, these functions are deactivated.
Reset Clock To Minute: resets the internal clock to the nearest minute. For
example, 3:03:10 would be reset to 3:03:00, while 3:53:40 would be reset to
3:54:00. Use this function to re-sync the 8400’s internal clock periodically
to your station’s master clock.
No Function: remote input is disabled.
3. End remote control interface programming.
When you are finished programming the remote control interface, press the
Escape button once to return to the System Setup screen.
Networking
[Skip this step if you do not wish to network to 8400, either for downloading software
upgrades or for PC Remote Control.]
As of version 1.0 and higher, Orban supports two different Ethernet PC Cards for use in
the 8400’s rear PC Card slot: The Linksys EC2T Combo PCMCIA Ethernet Card, and
the Linksys NP10T PCMCIA Ethernet 10BaseT Card. Use only one of these cards if you
wish to implement Ethernet networking with your 8400.
Do not install or remove a PC card in the 8400 when the 8400 is powered.
1. Installing the card:
A) Remove power from the 8400.
B) Insert the network card in the rear PC card slot.
