OPTIMOD-FM INSTALLATION
2-7
Two Composite Baseband Outputs are provided, each with independent output level
control. The second composite output can be reconfigured in software as a Pilot Refer-
ence Output useful for RDS (RBDS) subcarrier generators that require an external sync
reference. Each output uses a BNC connector.
Two SCA Inputs are provided for stations that use additional subcarriers (SCAs). Each
input uses a BNC connector.
Audio Input and Output Connections
Cable
We recommend using two-conductor foil-shielded cable (such as Belden 8451 or equiva-
lent), because signal current flows through the two conductors only. The shield does not
carry signal, and is used only for shielding.
Connectors
Input and output connectors are XLR-type connectors.
In the XLR-type connectors, pin 1 is CHASSIS GROUND, while pin 2 and
pin 3 are a balanced, floating pair. This wiring scheme is compatible with
any studio-wiring standard: If pin 2 or 3 is considered LOW, the other pin is
automatically HIGH.
Analog Audio Input
Nominal input level between –14 dBu and +8 dBu will result in normal operation of
the 8400.
(0 dBu = 0.775Vrms. For this application, the dBm @600Ω scale on voltme-
ters can be read as if it were calibrated in dBu.)
The peak input level that causes overload is dependent on the setting of the Analog
Input
Clip Level control. It is adjustable from 0 dBu to +27.0 dBu.
The electronically balanced input uses an ultra low noise and distortion differential
amplifier for best common mode rejection. It is compatible with most professional
and semi-professional audio equipment, balanced or unbalanced, having a source im-
pedance of 600Ω or less. The input is EMI suppressed.
Input connections are the same whether the driving source is balanced or unbalanced.
Connect the red (or white) wire to the pin on the XLR-type connector (#2 or #3) that
is considered HIGH by the standards of your organization. Connect the black wire to
the pin on the XLR-type connector (#3 or #2) that is considered
LOW by the stan-
dards of your organization.
