OPTIMOD-FM INSTALLATION
2-51
Diagnostic Operations
These provide a status report indicating essential information:
Command Response
ST«
8400 Status:
Ver. 2.1.x.x Bootrom: 4
mmm. dd, yyyy HH:MM:SS
On Air: LOUD-HOT+BASS
User Presets: 0
Memory Total: 16318464
Init Available: 13606912
Mem Available: 10022480
Mem Contiguous: 9420800
Heap Available: 15952
Heap Contiguous: 2048
Disk Size: 23998
Free Disk Space: 18978
PC Card 1: not installed
PC Card 2: not installed
Remote Control Interface Programming
[Skip this step if you do not wish to program the opto-isolated GPI remote control inter-
face at this time.]
Note: To facilitate doing EAS tests, units running pre-V1.0 software are hard-coded 8400
with remote 1 set for
Bypass and remote 2 set for Exit Test. With V1.0 and higher, 8400
remote control supports user-programmable selection of up to eight inputs for various
8400 functions. We recommend that you always upgrade to the latest available 8400
software.
1. Navigate to the System Setup: Network Remote screen.
2. Program one or more remote control interfaces.
To program a given remote input, use
Locate to highlight the input. As you
turn the control knob, the functions listed below will appear in the highlighted
field. A momentary pulse of voltage will switch most functions, except as
noted.
Preset Name: switches that preset on the air. Any factory or user preset may
be recalled by the control interface.
Input: Analog: selects the analog inputs.
