Orban OPTIMOD 8400 - Input;Output Circuit Board; Display Circuit Board; Composite Input;Output Circuit Board; Control Circuit Board

6-20
TECHNICAL DATA Orban Model 8400
Composite Input/Output Circuit Board
PART # DESCRIPTION COMPONENT IDENTIFIER
20039.750.01 RESISTOR, MF, 1/8W, 1%, 75.0 ohm R13 R14
20040.604.01 RESISTOR, MF, 1/8W, 1%, 604 ohm R5 R6 R7 R8
20130.162.01 RESISTOR, 1/8W, 1%, 1.62K R9 R10
20130.200.01 RESISTOR, 2.00K R11 R12
20131.200.01 RESISTOR, 20.0K 1% R1 R2 R3 R4
21139.000.01 CAPACITOR, X7R, 0.1UF, 10% C11 C12 C3 C4 C5 C6
21143.000.01 CAPACITOR, NPO, 1500PF, 1% C7 C8 C9 C10
21145.000.01 CAPACITOR, NPO, 5%, 100V, 33PF, 1206 C1 C2
24024.000.01 IC, OPA2134PA IC3
24025.000.01 IC, BUF634P, DIP8 IC1 IC2
29508.210.01 FILTER, EMI SUPPRESSION, 50V- L1 L2 L3 L4
29521.000.01 INDUCTOR, 3.9UH, JM391K L5 L6 L7 L8
Control Circuit Board
PART # DESCRIPTION COMPONENT IDENTIFIER
20080.301.01 RESISTOR, MF, 1/2W, 1%, 301 ohm R68
20121.100.01 RESISTOR, RF, 1/8W, 1%, 10 ohm R20 R59 R96 R97
20121.750.01 RESISTOR, TF, 1/8W, 1%, 75 ohm R30 R47 R78 R79 R80 R81 R83
R84 R85 R86 R94 R82
20123.499.01 RESISTOR, TF, 1/8W, 1%, 4.99K R89 R91
20129.301.01 RESISTOR, 301 ohm R130
20130.100.01 RESISTOR, 1.00K 1% R29 R36 R46 R49 R52 R55 R58
R61 R64 R117 R120 R92 R93
20130.162.01 RESISTOR, 1/8W, 1%, 1.62K R69 R70
20130.200.01 RESISTOR, 2.00K R124
20130.221.01 RESISTOR, 2.21K R19
20130.332.01 RESISTOR, 1% 3.32K R76 R140
20130.365.01 RESISTOR, 1/8W, 1%, 3.65K R90
20130.475.01 RESISTOR, 4.75K R31 R32 R33 R34
20130.562.01 RESISTOR, 1/8W, 1%, 5.62K R75
20131.140.01 RESISTOR, 14.0K R126 R87
20131.200.01 RESISTOR, 20.0K 1% R88
20131.301.01 RESISTOR, 30.1K R141
20131.499.01 RESISTOR, 1/8W, 1%, 49.9K R23
20132.100.01 RESISTOR, 100K R24 R28 R45 R48 R51 R54 R57
R60 R63 R66 R67 R116 R95
R105 R106 R107 R108 R109
R110 R111 R112
20132.332.01 RESISTOR, 332K R21
21140.000.01 CAPACITOR, NPO, 470PF, 1% C19 C36
21141.000.01 CAPACITOR, NPO, 1000PF, 1% C18 C23 C25 C28 C31 C34 C47
C58 C63 C70
21145.000.01 CAPACITOR, NPO, 5%, 100V, 33PF, 1206
C37
21146.310.01 CAPACITOR, 0.01uf, 10% C17 C22 C24 C27 C30 C33 C45
C57 C62 C68 C94
21147.022.01 CAPACITOR, 22pf, 1% C20 C89 C92 C93
21149.015.01 CAPACITOR, 15pf, 1% C40
21150.133.01 CAPACITOR, 330pf, 1% C39
21154.433.01 CAPACITOR, 0.33uf, 20% C133, C134, C135
21209.710.01 CAPACITOR, RADIAL LEADS, 100uF, 63V, 20% C100
