3-48
OPERATION ORBAN Model 8400
Customizing the Settings
Each of these presets can be edited with the Less/More control to optimize the trade-off
between loudness and distortion according to the needs of the format. They can be further
edited with Basic, Intermediate or Advanced Modify to fine-tune them.
The controls in the Five-Band structure give you the flexibility to customize your station
sound. Nevertheless, as with any audio processing system, proper adjustment of these
controls requires proper balancing of the trade-offs between loudness, density, and audi-
ble distortion. The following provides the information you need to adjust the Five-Band
structure controls to suit your format, taste, and competitive situation.
The Five-Band Structure’s Full Setup Controls
The tables below summarize the Multiband and Band Mix controls in the dynamics sec-
tion. The AGC, Equalizer, Stereo Enhancer, and Clipper controls are common to both the
Two-Band and Five-Band structures and are discussed in their own sections in Section 3.
Multiband Controls
Intermediate Name Advanced Name Range
Drive MB Drive 0 ... 25
Release (see MB Attack/Rel screen) Slow, Slow2, Med, Med2,
MFast, MFast2, Fast
Gate Threshold Gate Thres Off, –44 ... –15 dB
Clipping MB Clipping –4.0 ... +5.0 dB
Down Expander Down Expand Off, –6.0 … 12.0 dB
Multiband Clipping Multiband Clipping –4.0 ... +5.0
Band 2>1 Coupling (see Band Mix screen) 0 ... 100 %
Band 2>3 Coupling (see Band Mix screen) 0 ... 100 %
Band 3>2 Coupling (see Band Mix screen) 0 … 100 %
Band 3>4 Coupling (see Band Mix screen) 0 ... 100 %
Band 4>5 Coupling (see Band Mix screen) 0 ... 100 %
--- B1 Compression Threshold –16.00 … 0.00, Off
--- B2 Compression Threshold –16.00 … 0.00, Off
--- B3 Compression Threshold –16.00 … 0.00, Off
--- B4 Compression Threshold –16.00 … 0.00, Off
--- MB Limit Thr –3.0 +6.0, Off
--- Max Dist Ctrl 0 … 18 dB
--- B5 Clip Thre –16.00 … –1.3, Off
--- HF Limiter Off, –23.8 ... 0.0 dB
--- DownExpStCpl Off, On
--- B1/B2 Xover 100. 200 Hz
--- Speech Thr –4.0 ... +5.0 dB
Table 3-7: Multiband Controls
MB Attack/Release
Intermediate Name Advanced Name Range
Release MB Release Slow, Slow2, Med, Med2,
MFast, MFast2, Fast
