Orban OPTIMOD 8400 - Front Panel Subassembly

6-18
TECHNICAL DATA Orban Model 8400
29015.000.01 TRANSFORMER, AES/EBU T500 T501 T502
29508.210.01 FILTER, EMI SUPPRESSION, 50V- L100 L102 L104 L106 L305 L306
L307 L500 L501 L502 L503 L504
L505 L200 L201 L202 L203
29521.000.01 INDUCTOR, 3.9UH, JM391K L204 L205 L206 L207 L308 L309
L310
29522.000.01 INDUCTOR, 1200UH, 5%, 1-M-10-22 L101 L103 L105 L107
29707.002.01 INDUCTOR, FERRITE POT CORE, 3.501mh L300 L312
29707.003.01 INDUCTOR, FERRITE POT CORE, 3.39mh L301 L313
44082.100.01 FIRMWARE, FM I/O, IC503, 8400 IC503
44083.100.01 FIRMWARE, FM I/O, IC602, 8400 IC602
20151.365.01 RESISTOR, 0.1% 3.65K R130 R133 R135 R136 R143
R145 R147 R148
20151.536.01 RESISTOR, 0.1%, 5.36K R102 R109 R117 R122
Front Panel Subassembly
PART # DESCRIPTION COMPONENT IDENTIFIER
19555.000.01 KEY, CAPACITOR, ENTER,
19556.000.01 KEY, CAPACITOR, ESCAPE
19557.000.01 KNOB, J KNOB,
19558.000.01 KNOB, ROTARY,
19559.000.03 KNOB, VOLUME CONTROL
43037.000.01 CABLE, 6P MOLX IF-HP J2 TO J1
43038.000.01 CABLE, 16P, IDC-IDC 7.5
50531.000.01 PANEL, FRONT, MOLDED FACE
50532.000.01 PANEL, FRONT, MOLDED LEFT BEZEL
50533.000.01 PANEL, FRONT, MOLDED RIGHT BEZEL
50534.000.01 LENS, FRONT PANEL, 8400
52000.300.01 COLOR LCD DISPLAY
Display Circuit Board
PART # DESCRIPTION COMPONENT IDENTIFIER
240-003 INDUCTOR, 2A, 2.2UH L1
20121.100.01 RESISTOR, RF, 1/8W, 1%, 10 ohm R1
20129.100.01 RESISTOR, 100 ohm R27
20130.100.01 RESISTOR, 1.00K 1% R14 R29
20130.221.01 RESISTOR, 2.21K R4 R6 R11 R12
20130.562.01 RESISTOR, 1/8W, 1%, 5.62K R28
20131.100.01 RESISTOR, 10K R15 R16 R17 R18 R19 R20 R25
R30 R31 R32 R33 R34
20131.140.01 RESISTOR, 14.0K R3 R5 R8 R10
20131.200.01 RESISTOR, 20.0K 1% R2 R7 R9 R13
20132.100.01 RESISTOR, 100K R21 R24 R26
20135.121.01 RESISTOR, 1.21M R22 R23
20896.000.01 DIGITALLY-CONTROLLED POT, MAX5160LEUA U7
21139.000.01 CAPACITOR, X7R, 0.1UF, 10% C3 C4 C5 C8 C11 C12 C13 C15
C18 C19 C20
21142.000.01 CAPACITOR, NPO, 100PF, 1% C17
21147.022.01 CAPACITOR, 22pf, 1% C9 C10
21157.218.01 CAPACITOR 1800PF 50V 5% C1 C2
21318.510.01 CAPACITOR, TANTALUM, 1.0uF, 35V, B-CASE C6 C7
