Orban OPTIMOD 8400 - Page 223

OPTIMOD-FM TECHNICAL DATA
6-17
20131.249.01 RESISTOR , 1/8W, 1% 24.9K R203 R209 R213 R216
20131.499.01 RESISTOR, 1/8W, 1%, 49.9K R222 R223 R228 R229 R501
R504 R507 R513 R520 R524
R525 R526 R239 R240 R241
R242
20131.825.01 RESISTOR, 1/8W, 1%, 82.5K R104 R123 R303 R320
20132.154.01 RESISTOR, 1/8W, 1%, 154K R328 R329
20511.310.01 TRIMPOTS, 10K, 20%, TOP ADJ VR200 VR201
21112.210.01 CAPACITOR, CER, 0.001UF, 1KV, 10% C100 C102 C104 C106
21123.510.01 CAPACITOR, RADIAL LEADS, 1.0uF, 50V, 20% C224 C230
21137.282.01 CAPACITOR, 8200PF, +-15%, 50V C507 C512 C518
21137.447.01 CAPACITOR .47UF 25V 10% 1206 C113 C117 C340 C350 C503
C506 C511
21138.247.01 CAPACITOR, SMD1206, 4700PF, 50V, 5% C109 C110 C115 C116
21140.000.01 CAPACITOR, NPO, 470PF, 1% C217 C218 C219 C220 C336
C339 C344 C349
21141.000.01 CAPACITOR, NPO, 1000PF, 1% C226 C228 C337 C347 C517
C519 C521
21142.000.01 CAPACITOR, NPO, 100PF, 1% C338 C348
21143.000.01 CAPACITOR, NPO, 1500PF, 1% C221 C222 C225 C227
21144.000.01 CAPACITOR, 5%, 100V, 47PF C101 C103 C105 C107 C108
C114 C333 C343
21145.000.01 CAPACITOR, NPO, 5%, 100V, 33PF, 1206 C231 C335 C346 C351
21156.020.01 CAPACITOR, 12pf C223 C229 C334 C345
21263.710.01 CAPACITOR, RADIAL LEADS, 100uF, 25V, 10% C304 C305 C308 C325 C326
C329
21318.510.01 CAPACITOR, TANTALUM, 1.0uF, 35V, B-CASE C200 C201 C515 C516 C232
22101.001.01 DIODE, 1N4148WT/R CR101 CR102 CR106 CR107
22102.001.01 DIODE 1N5711TR CR500
22106.000.01 DIODE, SMCJ26C, TRAN20RB CR100 CR103 CR104 CR105
CR202 CR203 CR204 CR205
23415.000.01 TRANSISTOR, JFET SST113 SURFACE MOUNT Q200 Q201 Q202 Q203
24024.000.01 IC, OPA2134PA IC100 IC102
24634.000.01 IC, OCTAL 3 STATE NONINVR IC504
24728.302.01 IC, QUAD, SPST SW, DIP/16 IC101 IC103
24748.000.01 IC, LM339M S014 IC210
24857.000.01 IC 74HC374 DLATCH SOL20 IC108 IC209
24858.000.01 IC, SO/14, SURFACE MOUNT IC604
24896.000.01 IC, SO/16, SURFACE MOUNT IC507
24900.000.01 IC, HEX INVERTER, SURFACE MOUNT IC603
24924.000.01 IC CSS3310KS IC203
24938.000.01 IC, SINGLE 2 INPUT, SURFACE MOUNT IC508
24957.000.01 IC, PCM1704U IC300 IC304
24958.000.01 IC, DRV134PA, DIP IC207 IC208
24960.000.01 IC, OPA2134UA IC104 IC105 IC106 IC201 IC202
IC204 IC206 IC302 IC305
24961.000.01 IC, OPA627AP IC308 IC309
24962.000.01 IC CS8420CS REV D IC500 IC501 IC502
24963.000.01 IC, 5383 VS IC107
24992.000.01 IC, 74AHCT244 SOIC IC600 IC601
24997.000.01 IC, DAC AK4393 SSOP28 IC211
27106.000.01 CONNECTOR, BNC, RIGHT ANGLE, PC MOUNT J301 J302
27147.008.01 IC, SOCKET, DIP, 8 PINS, DUAL IC208 IC100 IC102 IC207
27147.016.01 IC, SOCKET, DIP, 16 PIN, DUAL IC101 IC103
27147.020.01 IC, SOCKET, DIP, 20 PIN, DUAL IC602
27174.044.01 IC, SOCKET, 44 PIN, LOW PROFILE IC503
