Ormazabal ekor.rps User Manual

IG-150-EN version 04; 03/10/16
130
Other functions General instructions
ekor.rps
Nr. Bytes Format Specication Data
2
Word PROCOME V
r
* 1.2 V
A
module
2
Word PROCOME V
r
* 1.2 V
B
module
2
Word PROCOME V
r
* 1.2 V
C
module
2
Word PROCOME V
r
* 1.2 V
AVERAGE
module
2
Word PROCOME √3*V
r
* 1.2 V
AB
module (compound voltage)
2
Word PROCOME √3*V
r
* 1.2 V
BC
module (compound voltage)
2
Word PROCOME √3*V
r
* 1.2 V
CA
module (compound voltage)
2
Word PROCOME √3*V
r
* 1.2 V
CAVERAGE
module (compound voltage)
2
Word PROCOME V
r
* 1.2 V
n
module (neutral)
2
Word PROCOME V
r
* 1.2 V module Syncrocheck
2
Word PROCOME 1.2 [A] I
A
module*
2
Word PROCOME 6 [A] I
A
module**
2
Word PROCOME 1.2 I
B
module*
2
Word PROCOME 6 I
B
module**
2
Word PROCOME 1.2 I
C
module*
2
Word PROCOME 6 I
C
module**
2
Word PROCOME 1.2 I
AVERAGE
module*
2
Word PROCOME 6 I
AVERAGE
module**
2
Word PROCOME 1.2 I
n
module*
2
Word PROCOME 6 I
n
module**
2
Word PROCOME 1.0 I
ns
module (sensitive)*
2
Word PROCOME 6 I
ns
module (sensitive)**
2
Word PROCOME 1.0 I
na
module (isolated)*
2
Word PROCOME 6 I
na
module (isolated)**
2
Word PROCOME 1.2 Current maximeter*
2
Word PROCOME 6 Current maximeter **
2
Word PROCOME 3 * V
r
* 1.2 * 1.2 P (active power)*
2
Word PROCOME 3 * V
r
* 1.2 * 6 P (active power)**
2
Word PROCOME 3 * V
r
* 1.2 * 1.2 Q (reactive power)*
2
Word PROCOME 3 * V
r
* 1.2 * 6 Q (reactive power)**
2
Word PROCOME 3 * V
r
* 1.2 * 1.2 S (apparent power)*
2
Word PROCOME 3 * V
r
* 1.2 * 6 S (apparent power)**
2
Word PROCOME 70 Frequency
2
Word PROCOME 70 Frequency Syncrocheck
2
Word PROCOME 1 Phase A power factor
2
Word PROCOME 1 Phase B power factor
2
Word PROCOME 1 Phase C power factor
2
Word PROCOME 1 Average power factor
2
Word PROCOME 100 Distortion in I
A
2
Word PROCOME 100 Distortion in I
B
2
Word PROCOME 100 Distortion in I
C
2
Word PROCOME 100 Distortion in V
A
2
Word PROCOME 100 Distortion in V
B
2
Word PROCOME 100 Distortion in V
C
2
Word PROCOME 100 Average distortion in current
2
Word PROCOME 100 Average distortion in voltage
2
Word PROCOME 100 Distorsión media en tensiones
2
Word PROCOME 1.2 Zero sequence current
2
Word PROCOME 6 Zero sequence current
2
Word PROCOME 1.2 Positive sequence current
2
Word PROCOME 6 Positive sequence current
2
Word PROCOME 1.2 Negative sequence current
2
Word PROCOME 6 Negative sequence current
* With standard ratings.
** With specied ratings.
Continued on next page
