Ormazabal ekor.rps User Manual

IG-150-EN version 04; 03/10/16
131
General instructions
ekor.rps
Other functions
Continuation
N° Bytes Formato Specication Data
2
Word PROCOME V
r
* 1.2 Zero sequence voltage
2
Word PROCOME V
r
* 1.2 Positive sequence voltage
2
Word PROCOME V
r
* 1.2 Negative sequence voltage
2
Word PROCOME 100 (%) Distance to fault
2
Word PROCOME 100 (°) Unit temperature
2
Word PROCOME
286 (source 125/220 V
dc
)
62.4 (source 24/48 V
dc
)
V
dc
measurement
2
Word PROCOME 4095 Total number of openings 52
2
Word PROCOME 4095 Reclosing counter
2
Word PROCOME 4095 Counter 1st reclosing
2
Word PROCOME 4095 Counter 2nd reclosing
2
Word PROCOME 4095 Counter 3rd reclosing
2
Word PROCOME 4095 Counter 4th reclosing
2
Word PROCOME 4095 Number of openings 52 per trip
2
Word PROCOME V
r
* 1.2 * 6 P (active power) phase A
2
Word PROCOME V
r
* 1.2 * 6 P (active power) phase B
2
Word PROCOME V
r
* 1.2 * 6 P (active power) phase C
2
Word PROCOME V
r
* 1.2 * 6 Q (reactive power) phase A
2
Word PROCOME V
r
* 1.2 * 6 Q (reactive power) phase B
2
Word PROCOME V
r
* 1.2 * 6 Q (reactive power) phase C
2
Word PROCOME 3 * V
r
* 1.2 * 6 P (maximum active power)
2
Word PROCOME 3 * V
r
* 1.2 * 6 Q (maximum reactive power)
2
Word PROCOME V
r
* 1.2 * 6 P maximum phase A
2
Word PROCOME V
r
* 1.2 * 6 P maximum phase B
2
Word PROCOME V
r
* 1.2 * 6 P maximum phase C
2
Word PROCOME V
r
* 1.2 * 6 Q maximum phase A
2
Word PROCOME V
r
* 1.2 * 6 Q maximum phase B
2
Word PROCOME V
r
* 1.2 * 6 Q maximum phase C
2
Word PROCOME 40 [A] I last fault phase A*
2
Word PROCOME 200 I last fault phase A**
2
Word PROCOME 40 I last fault phase B*
2
Word PROCOME 200 I last fault phase B**
2
Word PROCOME 40 I last fault phase C*
2
Word PROCOME 200 I last fault phase C**
2
Word PROCOME 40 I last fault phase neutral*
2
Word PROCOME 200 I last fault phase neutral**
2
Word PROCOME 1 I last fault sensitive neutral*
2
Word PROCOME 10 I last fault sensitive neutral**
2
Word PROCOME 4095 kI
2
sum pole A
2
Word PROCOME 4095 kI
2
sum pole B
2
Word PROCOME 4095 kI
2
sum pole C
2
Word PROCOME V
r
* 1.2 * 20 Impedance Module
* With standard ratings.
** With specied ratings.
Table 8.1. Phase current values
