IG-150-EN version 04; 03/10/16
132
Other functions General instructions
ekor.rps
The background scale indicated corresponds to a count
number of 4095.
The digital signals concerned (changes and states) are
designated as “available signals” in the corresponding
appendix. With any protocol, it can be programmed which
signals are going to be sent and with which number.
There is a changes queue with 400 records. The signals
changes, which are sent via the PROCOME protocol, are
extracted from these records.
Each record contains the digital signals which have changed
within the same millisecond.
This is, if the status of 10 digital signals changes within the
same millisecond, this change only takes one queue record.
Whereas, when sent via communications, they turn into 10
independent changes.
Therefore, in the worst case scenario, where only one signal
changes in each queue record, the queue contains the latest
400 digital changes occured in the equipment. This number
increases considerably if more than one signal changes
within the same millisecond, which is very usual.
The statistical data initialisation commands make possible
setting 0 the reclosing counters, the energy counters, the
maximeter and setting the initial value programmed as
sumkI
2
.
The command orders in any protocol can be programmed
among the following ones:
Action ISC Default (in PROCOME)
Open breaker
programmable 22
Close breaker
programmable 24
Activate any relay from 1 to 14 (pulse)
programmable 1a14
Set recloser out of service
programmable 28
Set recloser in service
programmable 26
Table 1 activation
programmable 60
Table 2 activation
programmable 61
Table 3 activation
programmable 62
Table 4 activation
programmable 63
Table 5 activation
programmable 64
Table 6 activation
programmable 65
Set in local
programmable not programmed
Set in telecommand
programmable not programmed
Phase instantaneous locking
programmable not programmed
Phase instantaneous unlocking
programmable not programmed
Neutral instantaneous locking
programmable not programmed
Neutral instantaneous unlocking
programmable not programmed
Phase time locking
programmable not programmed
Phase time unlocking
programmable not programmed
Neutral time locking
programmable not programmed
Neutral time unlocking
programmable not programmed
Sens. Neutral inst locking
programmable not programmed
Sens. Neutral inst unlocking
programmable not programmed
Sens. Neutral time locking
programmable not programmed
Sens. Neutral time unlocking
programmable not programmed
Phase inst. locking H1 (high level)
programmable not programmed
Phase inst. unlocking H1 (high level)
programmable not programmed
Neutral inst. locking H1 (high level)
programmable not programmed
Neutral instant. unlocking H1 (high level)
programmable not programmed
Phase instant. locking H2 (2
nd
group)
programmable not programmed
Phase instant. unlocking H2 (2
nd
group)
programmable not programmed
Neutral instant. locking H2 (2
nd
group)
programmable not programmed
Neutral instant. unlocking H2 (2
nd
group)
programmable not programmed
Phase time locking H2 (2
nd
group)
programmable not programmed
hase time unlocking H2 (2
nd
group)
programmable not programmed
Continued on next page
