Section 2 Installation
2 - 8
May 1992
MX-5050 Operation and Maintenance Manual
SW2-3
This switch selects whether the audio signal is muted during the time from
when the STOP button is pressed until the machine actually stops.
ON: Not Mute
OFF: Mute
SW2-4
This switch selects whether the audio signal is muted during Fast Wind
modes other than Fast Wind Cue mode.
ON: Not Mute
OFF: Mute
SW2-5
This switch selects whether the audio is muted during the time from when
the PLAY button is pressed until the tape enters Play mode.
ON: Not Mute
OFF: Mute
SW2-6, 2-7
These switch settings determine the machine type. These switches are set at
the factory and should not be changed.
SW2-6 SW2-7 Type Tape Rehearsal Size
ON ON 8CH 1/2" O O
OFF ON 4CH 1/2" O O
ON OFF 4CH 1/4" O O
SW2-8
Not Used
Table 2-6
Machine Type
