OTARI MX-5050 - Page 44

Section 3 Controls and Indicators
3 - 10
May 1992
MX-5050 Operation and Maintenance Manual
POWER
GROUND
PARALLEL I/O
LINE INPUTLINE OUTPUT
CH 2CH 1 CH 1CH 2CH 1
CH 2
MIC INPUT
MIC ATTENUATOR
OdB-2OdB OFF
REF FLUX
LOW MID HIGH
EQUALIZATION
IEC NAB
OUTPUT LEVEL
LOW HIGH
32
1
4
5
6
7
8
9
10
POWER
GROUND
PARALLEL I/O
LINE INPUTLINE OUTPUT
CH 2CH 1 CH 1CH 2CH 1
CH 2
MIC INPUT
MIC ATTENUATOR
OdB-2OdB OFF
REF FLUX
LOW MID HIGH
EQUALIZATION
IEC NAB
OUTPUT LEVEL
LOW HIGH
1. Line Output Connector
2. Line Input Connector
3. Mic Input Connector
4. Mic Attenuator Switch
5. REF FLUX Level Select Switch
6. Equalizer Select Switch
7. Output Level Select Switch
8. Ground Terminal
9. Parallel I/O Connector
10. Power Connector
Figure 3-6
Audio Connector Panel (MKIV-2)
