5 Product Specic Instructions - Rehab Buggy

– Eco Buggy –

For assembly of the xation kit HR32549700 you will need the following tools: a ring wrench size 10, an Allen

wrench size 4, pointed pliers

Guidance for tting the Pelvic Belt

Assembly tip: Important - Only attach the anchor plates to the frame at the indicated points, using the pipe

clips and screws provided. Use pointed pliers to keep the pipe clips closed whilst assembling the anchoring

plate and tightening the screws. Do not fully tighten the screws until the pipe clips and anchoring plates have

been positioned correctly. To check this fold the buggy and check that the anchoring plates do not make contact

with the frame.

Assemble two D20 pipe clips

around the front frame on either

side of the unit. Then attach the an-

chor plates using the screws pro-

vided so the nuts and hook symbol

are facing outwards.

Assemble two D20 pipe clips

around the rear frame on either side

of the unit and attach the anchor

plates using the screws provided

so the nuts are on the inside and

the hook symbol is facing outwards.

Adjust the position of the front an-

choring plates by rotating them out-

wards by about 20° – Folding test!

Attaching the anchoring points to the product

This rehab buggy is equipped with back angle adjustment. Before starting check the backrest is in

almost upright position and secure it by tightening the star grips on the left and right sides of the

push handles. Observe the specications in the Instructions for Use Manual of the Rehab Buggy.

Eco-Buggy showing the correct

positioning of the tie-down straps.

Pass one end of the pelvic belt through the space between the frame and

backrest. Now clip the pelvic belt buckle onto the "Anchor Pin" on the

side frame anchoring plate, then repeat on the opposite side for the other

half of the pelvic belt.
