61
7 Product Specic Instructions – Manual Wheelchairs
– Avantgarde VR –
For assembly of the 481S00=SK018 xation kit you will need the following tools:
ring wrenches sizes 10 and 13, Allen wrenches sizes 4 and 5
Guidance for tting the Pelvic Belt
Assembly tip: Important – Only attach the anchor plates to the frame at the indicated points, using the half-
shells and screws provided. Do not fully tighten the screws until the half-shells and anchoring plates have been
positioned correctly.
Mount anchoring points to the front
frame on either side of the unit, just
behind the castor heads, so the x-
ing eyelets are facing outwards.
Mount anchor plates to the inner sides on the left and right of the rear
frame part, so that the xing eyelets and anchor symbols are facing out-
wards.
Pass one end of the pelvic belt through from the seat side to the outside.
Now clip the pelvic belt buckle onto the "Anchor Pin" on the anchoring
plate. Then repeat on the opposite side for the other half of the pelvic belt.
Attaching the anchoring points to the product
Avantgarde VR showing the correct
positioning of the tie-down straps.
This wheelchair might be equipped with back angle adjustment. Before starting adjust the backrest
to almost upright position and check if the locking mechanism on either side has engaged. Observe
the specications in the Instructions for Use Manual of the wheelchair.
Unfortunately, the xation kits cannot be used with all equipment and accessories combinations. For
existing restrictions in the combination of equipment and accessories please refer to the 647F231
Info Sheet.
