9.3 Warranty
Further information on the warranty terms and conditions can be obtained from the qualified personnel that has fit
ted this product or the manufacturer's service (see inside back cover for addresses).
9.4 Service life
Expected service life: 5 years.
The design, manufacturing and requirements for the intended use of the product are based on the expected ser
vice life. These also include the requirements for maintenance, ensuring effectiveness and the safety of the
product.
Using the product beyond the specified expected service life leads to increased residual risk and should only take
place subject to the due diligence and deliberations of qualified personnel.
If the service life is reached, the user or a responsible attendant should contact the qualified personnel who fitted
the product or the manufacturer's servicing department (see inside rear cover or back page for address). Here the
user can obtain information about known risks and the current options for refurbishing the product.
10 Technical data
INFORMATION
► Much of the technical data below is given in mm. Please note that product settings – unless otherwise spe
cified – cannot be adjusted in the mm range but only in increments of approx. 0.5cm or 1cm.
► Note that the values achieved during adjustment may deviate from the values specified below. The deviation
can be ±10mm and ±2°.
Application class (according to DIN EN 12184)
Class A
Application class (according to DIN EN 12184)
ClassB
Drive type
Front-wheel drive
Drive type
Rear-wheel drive
Drive type
Mid-wheel drive
Mobility base
Size 1
Mobility base
Size 2
Weight (minimum/maximum)
Minimum weight 100kg (220lbs)
Maximum weight 200kg (441lbs)
Weight*
Equipped with mobility base 1 + standard
seat
from 110kg (from 242.5lbs)
Equipped with mobility base 2 + standard
seat
from 125kg (from 275.5lbs)
Equipped with mobility base 1 + VAS seat from 115kg (from 253.5lbs)
Equipped with mobility base 2 + VAS seat from 130kg (from 286.5lbs)
* The specified weights vary according to the accessories and selected model.
Load capacity
Maximum load capacity
(User weight + luggage)
See nameplate for precise information
