Otto Bock Juvo - Spring-Mounted Caster Wheel Swing Arm

82
Releasing the caster wheel swivel lock
1) Push the release lever up (see fig.82, item1).
2) The caster wheel swivel lock bolt (see fig.82,
item2) releases the front fork again. The caster
wheels are unlocked and can swivel freely again.
6.16.5 Spring-mounted caster wheel swing arm
83
The spring elements on the caster wheel swing arms
increase driving comfort, especially when driving on
rough terrain.
They also improve traction.
84
The spring elements on the front and rear caster wheel
swing arms improve driving comfort, especially when
driving on rough terrain.
They also improve traction.
91Juvo
Use
