Otto Bock Juvo - Reducing the Transportation Size

CAUTION
Securing the power wheelchair insufficiently during transport
Crushing, pinching of body parts due to failure to observe transportation instructions
► During transportation in vehicles or aircraft, on lifting platforms or in lifts, turn the control unit of the power
wheelchair off and lock the brake.
► The power wheelchair must be secured in accordance with the regulations for the transport device.
► During transport in a vehicle, the power wheelchair must be secured sufficiently with cargo straps. Only
attach the cargo straps to the corresponding transportation eyelets and specified tie-down points.
NOTICE
Lifting the power wheelchair incorrectly
Damage to the power wheelchair due to failure to observe transportation instructions
► Hoisting devices used for transportation must have a sufficient capacity. For more information about weight,
see the section "Technical data" (see Page111).
► Do not attach the hoisting devices on moveable or adjustable components.
► Ensure that the seat is lowered all the way and the backrest is in a vertical position prior to loading and for
transporting the power wheelchair.
6.17.2 Reducing the transportation size
The transportation size can be reduced in a few steps to make transporting the product easier.
93
Preparing for transport
1) Fold the backrest forward and onto the seat surface
(see Page23).
2) Remove the side panels (see Page19). Place the
side panel on the seat.
3) Remove the legrests (see Page22).
94
Preparing for transport
1) Fold the backrest forward and onto the seat surface
(see Page23).
2) Remove the side panels (see Page19). Place the
side panel with control panel on the seat.
3) Remove the legrests (see Page22).
97Juvo
Use
