**) Depending on programming, switching between forwards and backwards can be carried out by simply pressing
the user switch or through an automatic change in direction by pressing the front/back button.
Switching between forwards and reverse using the user switch
Pressing the user switch once switches the direction for the front/back button. You can switch from Driving mode
to Menu mode and back by double-clicking the user switch during standstill.
Pressing the user switch while driving triggers an emergency stop.
Switching between driving forwards and in reverse using automatic change in direction by activating the
front/back button
After pressing and releasing the "front/back" button, the command is automatically interpreted in the opposite dir
ection the next time the button is activated. This sequence must be completed within a specified period of time
(typically 2 seconds; can be changed using programming). If the sequence is not finished within this period, activa
tion of the button is interpreted as a driving command in the previously set direction (no change in direction).
You can switch from Driving mode to Menu mode and back by briefly pressing the user switch (approx. 1s) during
standstill.
Pressing the user switch while driving triggers an emergency stop.
6.15.4.3.1 User switch
Operating with user switch
When the LCD monitor (Omni module) is used as part of the special control, the qualified personnel may also have
connected a separate user switch.
Function (standard setting): When the user switch is pressed, the control device switches from driving mode to
the menu. Here the user can control the seat functions or use additional functions, suchas environmental control
via IR.
In standard programming, the system first toggles through the individual seat functions. The "Exit" option is then
displayed, which can be used to return to Drive mode. If the user switch is pressed again while a seat function is
displayed, the system moves through the operating options for the specific seat function, i.e."Up", "Down" or
"Exit". The corresponding action can also be triggered by pressing the user switch at this level.
Pressing the user switch while driving triggers an emergency stop.
INFORMATION
The standard setting can be adapted to the user's abilities by the qualified personnel through technical program
ming. Have the qualified personnel instruct you in the specific function of the user switch.
Operating without user switch
The special controls assembled with the LCD monitor can also be implemented without a user switch. This can be
helpful if the user is unable to operate a user switch.
In this case the control device – depending on the programming – starts forexample in the menu. When the "Exit"
option is displayed, it is possible to return to Drive mode.
6.15.4.4 4-button control
The following functions are typically assigned to the buttons:
4 buttons Drive mode Menu mode*
Forward Forwards Scroll up in list
Back Reverse Scroll down in list
Right Turn right Select menu item
Left Turn left
*) Sequence mode can also be set for menu selection depending on programming. The menu entries can be
scrolled through here by pressing the user switch.
You can switch from Driving mode to Menu mode and back by briefly pressing the user switch (approx. 1s) during
standstill.
Pressing the user switch while driving triggers an emergency stop.
6.15.4.4.1 User switch
Operating with user switch
When the LCD monitor (Omni module) is used as part of the special control, the qualified personnel may also have
connected a separate user switch.
