Otto Bock Juvo - Preparing for Transport

95
Preparing for transport
1) Fold the back support forward and onto the seat
surface (see Page23).
2) Remove the side panels (see Page19). Place the
side panel with control panel on the seat.
3) Remove the legrests (see Page22).
6.17.3 Preparing for transport
96
Transporting the power wheelchair
1) Position the power wheelchair in its transport loca
tion.
2) Turn the control unit off (see Page25ff.).
3) Verify brake locking. It should not be possible to
push the power wheelchair.
If needed: Lock the brake (see Page50).
4) Use the eyebolts and cargo straps to attach the
power wheelchair to the transport vehicle (see
arrows).
97
Transporting the power wheelchair
1) Position the power wheelchair in its transport loca
tion.
2) Turn the control device off (see Page25ff.).
3) Verify brake locking. It should not be possible to
push the power wheelchair.
If needed: Lock the brake (see Page50).
4) Use cargo straps to attach the power wheelchair to
the transport vehicle. To do so, use the eyebolts on
the frame (see fig.97, right) and the opposite
caster wheel swing arms (see fig.97, left).
INFORMATION: Place respectively 2x one belt
loop around each caster wheel swing arm in
the marked area.
98
