Control device
Model R-Net (controller in combination with TEN° control panel)
Max. output current per motor 120A (seat functions are controlled via the separate actuator module)
Force for operating the joystick on the
standard control panel
1.6N
Control device accessories
Model R-Net actuator module for controlling additional seat functions
Max. output current per motor 90A
Allowable environmental conditions
Operating temperature -15°C to +40°C (5°F to +104°F)
Transport and storage temperature -15°C to +40°C (5°F to +104°F)
Corrosion protection
Corrosion protection Cathodic dip coating / powder coating
11 Appendices
11.1 Threshold values for wheelchairs transportable by train
INFORMATION
► The products in this series fully satisfy the minimum technical requirements of regulation (EU) No.1300/2014
regarding train accessibility for people with disabilities. However, not all versions can comply with all
threshold values due to different settings.
► With the help of the table that follows, you or the qualified personnel can take measurements and verify wheth
er the specific product in question meets the threshold values.
Feature Threshold value (according to regulation (EU) No.1300/2014)
Length 1200 mm (47.2"); plus 50 mm (2") for the feet
Width 700 mm (27.6"); plus 50 mm (2") on each side for the hands when
moving
Smallest wheels approx. 3" or greater according to the regulation, the smallest wheel
must be able to accommodate a gap measuring 75mm (3") horizont
ally and 50mm (2") vertically
Height max. 1375 mm (54.1"); including a 1.84m (72.5") large male wheel
chair user (95th percentile)
Turning radius 1500 mm (59.1")
Maximum weight 300 kg (661 lbs); for wheelchair with occupant, including baggage
Maximum obstacle height that can be
overcome
50 mm (2")
Ground clearance 60mm (2.4"); at an upward slope angle of 10°, ground clearance
must measure at least 60mm (2.4") under the foot rest for going for
ward at the end of the slope
Maximum inclination angle on which the
wheelchair will remain stable
6° (dynamic stability in all directions)
9° (static stability in all directions, also when wheel lock engaged)
