Dimensions and weights (rear-wheel drive; mobility base = size 1)
Arm support height (telescoping arm sup
port)
Standard seat: 205–275mm (8.1"–10.8")
Standard seat, Junior: 185–225mm (7.3"–8.8")
VAS seat: 185–255mm (7.3"–10")
Arm support length (standard) 260mm (10.2")
Foremost point of the side panel (meas
ured to back support)
Minimum: 300mm (11.8"); maximum: 580mm (22.8")
Overall width (standard motor/perform
ance or high performance motor)*
596 / 612mm (23.5" / 24.1")
Overall height (equipped with standard
seat)
850–1,110mm (33.4"–43.7")
Overall height (equipped with VAS seat) 850–1,110mm (33.4"–43.7")
Overall length (without leg support) 850mm (33.5")
Overall length (with leg support) Minimum: 1,050mm (41.3"); maximum: 1,250mm (49.2")
Transport weights** See "Weight", thereof weight of removable components:
Leg support (standard): approx. 2.2kg (4.9lbs)
Detachable side panel: approx. 3kg (6.6lbs)
Leg support (power, with aluminium foot support): approx. 6.5kg
(14.3lbs)
Minimum turning radius 965mm (38")
Ground clearance 80mm
Caster wheel tyre size
Drive wheel tyre size
9"/10"
14"
* Might be larger due to seat width adjustment. Overall width +180mm in the assembled state.
** Weight of the heaviest component
Dimensions and weights (rear-wheel drive; mobility base = size 2)
Arm support height (telescoping arm sup
port)
Standard seat: 205–275mm (8.1"–10.8")
Standard seat, Junior: 185–225mm (7.3"–8.8")
VAS seat: 185–255mm (7.3"–10")
Arm support length (standard) 260mm (10.2")
Foremost point of the side panel (meas
ured to back support)
Minimum: 300mm (11.8"); maximum: 580mm (22.8")
Overall width (standard motor/perform
ance or high performance motor)*
626 / 642mm (24.6" / 25.3")
Overall height (equipped with standard
seat)
850–1,110mm (33.4"–43.7")
Overall height (equipped with VAS seat) 850–1,110mm (33.4"–43.7")
Overall length (without leg support) 870mm (34.3")
Overall length (with leg support) Minimum: 1,050mm (41.3"); maximum: 1,250mm (49.2")
Transport weights** See "Weight", thereof weight of removable components:
Leg support (standard): approx. 2.2kg (4.9lbs)
Detachable side panel: approx. 3kg (6.6lbs)
Leg support (power, with aluminium foot support): approx. 6.5kg
(14.3lbs)
Minimum turning radius 965mm (38")
Ground clearance 80mm
Caster wheel tyre size
Drive wheel tyre size
9"/10"
14"
* Might be larger due to seat width adjustment. Overall width +180mm in the assembled state.
** Weight of the heaviest component
Dimensions and weights (mid-wheel drive; mobility base = size 1)
Arm support height (telescoping arm sup
port)
