Driving data (rear-wheel drive/front-wheel drive)
Static stability – sideways 10° (17.5%)
Maximum obstacle height With front-wheel drive: 75mm (3")
With rear-wheel drive: 50mm (2"); with curb climbing assist: 100mm
(4")
Braking distance (according to DIN EN
12184)****
At 6km/h (3.7 mph): 1,000mm (39.4") – horizontal
At 7.2km/h (4.4 mph): 1,200mm (47.2") – horizontal
At 10km/h [6.2 mph]: 2,100mm (82.7") – horizontal
At 14km/h [8.7 mph]: 3,900mm (153.5") – horizontal
* The specified speed can vary by±10%.
** The control device and the motors have to be protected against overloading. For this reason, the continuous
climbing ability depends on the overall weight (wheelchair weight + user weight + luggage) as well as the ground
conditions, exterior temperature, battery voltage and driving style of the user. In individual cases, the continuous
climbing ability can be significantly lower than the value specified.
*** Approved climbing ability with lowered seat functions, upright back support and lowered leg supports.
**** The braking distance can be correspondingly longer due to user weight, luggage, installed options and condi
tion of the tyres, and due to weather and surface conditions.
Driving data (mid-wheel drive)
Speed* See nameplate for precise information: 6km/h (3.7mph); 7.2km/h
(4.4mph); 10km/h (6.2mph)
Nominal incline (base model)** 10° (17.5%)
Dynamic stability – uphill*** 10° (17.5%)
Static stability – uphill/downhill 10° (17.5%)
Static stability – sideways 10° (17.5%)
Maximum obstacle height 65mm (2.5")
Braking distance (according to DIN EN
12184:2014)****
At 6km/h (3.7 mph): 1,000mm (39.4") – horizontal
At 7.2km/h (4.4 mph): 1,200mm (47.2") – horizontal
At 10km/h [6.2 mph]: 2,100mm (82.7") – horizontal
* The specified speed can vary by±10%.
** The control device and the motors have to be protected against overloading. For this reason, the continuous
climbing ability depends on the overall weight (wheelchair weight + user weight + luggage) as well as the ground
conditions, exterior temperature, battery voltage and driving style of the user. In individual cases, the continuous
climbing ability can be significantly lower than the value specified.
*** Approved climbing ability with lowered seat functions, upright back support and lowered leg supports.
**** The braking distance can be correspondingly longer due to user weight, luggage, installed options and condi
tion of the tyres, and due to weather and surface conditions.
Range (on level surfaces)*
Battery with 53Ah (C5) / 62Ah (C20) approx. 26 km (16 miles)
* The specified range was determined under defined conditions according to ISO 7176-4. In practice the range
can be reduced by up to 50%. For information on this, see the section "Range" in the instructions for use (user).
Range (on level surfaces)*
Battery with 63Ah (C5) / 74Ah (C20) Approx. 35km (22miles)
* The specified range was determined under defined conditions according to ISO 7176-4. In practice the range
can be reduced by up to 50%. For information on this, see the section "Range" in the instructions for use (user).
Range (on level surfaces)*
Battery with 75Ah (C5) / 80Ah (C20) approx. 40 km (24.8 miles)
* The specified range was determined under defined conditions according to ISO 7176-4. In practice the range
can be reduced by up to 50%. For information on this, see the section "Range" in the instructions for use (user).
Electrical system*
IP protection rating (according to DIN EN
60529)
IP44
Operating voltage 24VDC
Lighting
117Juvo
Technical data
