10.1 Appendix A: Specifications
10.1.1 Oscilloscope
Only if other instructions are provided, are all technical specifications applicable to the probe with
the 10X attenuation switch setting and the HDS-N series digital type oscilloscope. In order to be
up to these specifications, the oscilloscope should meet the following requirement.
■ The instrument should operate continuously for more than 30 minutes under the specified
operating temperature.
■ If the operating temperature is up to or larger than 5 Celsius degrees, the system function
menu must be opened to make the system perform a "Auto- calibration" procedure (see
"calibration" on P55).
Except those specifications marked with the word Typical, all specifications can be up to.
Sampling
Normal sampling
Peak detection
Average value
Sampling modes
100 MS/s----HDS1022M-N
500 MS/s----HDS2062M-N
Max 1 GS/s----HDS3102M-N
Sampling rate
Input
Input coupling DC, AC, Ground
● 1MΩ ± 2% connected in parallel with 20pF ±
5pF----HDS1022M-N
● 1MΩ ± 2% connected in parallel with 10pF ±
5pF----HDS2062M-N, HDS3102M-N
Input impedance
Probe attenuation coefficient 1X, 10X, 100X, 1000X
Max. Input voltage 400V (peak)
Channel delay time（typical） 150ps
Horizontal
0.25S/s～100MS/s----HDS1022M-N
0.25S/s～500MS/s----HDS2062M-N
0.25S/s～
1GS/s----HDS3102M-N
Sampling rate range
Waveform interpolation （sin x）/x
77
