OWON HDS-N Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
8.14 Using FFT
als into component frequencies, which the oscilloscope uses to display a
graph of the frequency domain of a signal, as opposed to the oscilloscope's standard time domain
graph. You can match these frequencies with known system frequencies, such as system clocks,
oscillators, or power supplies.
FFT in this oscilloscope can transform 2048 points of the time-domain signal into its frequency
components and the final frequency contains 1024 points ranging from 0Hz to Nyquist frequency.
n
An FFT breaks down sign
The following table describes the FFT menu:
Function Menu Setting Instructio
ON
OFF
Turn on FFT function
Turn off FFT function
FFT
Source
CH1
CH2
Select CH1 as FFT source
Select CH2 as FFT source
Window
Rectangle
Blackman
Hanning
Hamming
Select window for FFT.
Format
dB
Vrms
Set Vrms as vertical scale unit
Set dBVrms as vertical scale unit
Zoom
×1
×2
×5
×10
Set multiple ×1
Set multiple ×2
Set multiple ×5
Set multiple ×10
Taking the FFT operation for example, the operation steps are as follows:
screen.
are available
at the bottom of the screen.
3. Press F1 to set ON. The green waveform F is shown in the screen after calculation.
1. Press MENU key and the function menu appear on the right side of the
2. Press MENU ▲ or MENU ▼ key to select FFT MODE. Five items selectable
66
