OWON HDS-N Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
division, trigger level or time scale for CH1 or CH2. To back to Autoscale, Press AUTOSET.
6. The oscilloscope is always on main time base.
7. The oscilloscope is turned into Peak Detection mode if it is in Average mode.
8. When video triggering, the horizontal time scale is 50us. If one channel is showing edge
signal, the other channel is showing video one, the time scale refers to 50us as video one as
standard.
8.13 Record
Waveform record: The function provides you to set the time interval between the frames and
record the waveform up to 1000 numbers and get the better analysis effect more than before
through Playback and Save functions.
Four record modes: Record, Play back, Storage, OFF.
Record：Record the waveforms up till the set number of frames at specified time intervals.
Record menu list：
Menu Setting Instruction
Record
Play back
Storage
OFF
Select record mode.
Select play back mode.
Select storage mode.
Turn off all recorder functions.
Mode
End frame 1-1000 Set number of record frames.
Play
Stop
Press to start recording.
Press to stop recording.
Operate
Interval 1ms~1000s Set time interval between record frames.
－－＞
1/2
To next menu
ON
OFF
The waveforms are in the state of refreshing when recording.
The waveforms stop refreshing when recording.
Refreshed
Increase
Decrease
The value increases from that of end frame to time interval
The value decreases from that of end frame to time interval
Direction
－－＞
1/2
Back to previous menu.
Note: Both the waveforms are recorded at record mode. If one channel is off when recording, the
channel data is not available at Playback mode.
63
