OWON HDS-N Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
Play back: Play back the recorded waveforms.
Play back menu list：
Menu Setting Instruction
Loop
Single
Set repeat play mode.
Set single time play mode.
Play mode
Play
Stop
Press to start playback.
Press to stop playing.
Operate
Interval 1ms-20s Set up interval value between frames.
－－＞
1/2
To next menu
Start Frame 1-1000 Set start frame.
1-1000
Select current frame to be played.
Cur frame
End frame 1-1000 Set End frame.
Increase
Decrease
The value increases at the mode of setting start frame, cur frame and
end frame
The value decreases at the mode of setting start frame, cur frame and
end frame
Direction
－－＞
2/2
Back to previous menu.
Note: the Run/Stop button can also replay or continue the waveform display.
Storage: Store recorded waveforms in non-volatile memory according to the setup frames.
Storage menu list：
Menu Setting Instruction
Start Frame 1-1000 Set first frame to be saved.
End frame 1-1000 Set last frame to be saved.
Increase
Decrease
The value increases from the set start frame to the end frame
The value decreases from the set start frame to the end frame
Direction
－－＞
1/2
To next menu
Save Save recorded waveform to internal memory location.
Load Recall recorded waveform from internal memory location.
－－＞
2/2
Back to previous menu.
64
