OWON HDS-N Series Handheld DSO & DMM 10-Appendix
81
Diode
Voltage reading: 0 V ～1.5 V.
On-off Test
There is a beep sound when the on-resistance is less than 50Ω.
10.1.3 General Specifications
Basic parameter
Mechanical dimension 18 cm×11.5cm×4cm
Weight 645 g
Power consumption
＜ 6 W----HDS1022M-N，HDS3102M-N
＜ 7 W----HDS2062M-N
Display type 3.7" color liquid crystal display
Display resolution 640 (horizontal) ×480 (vertical) pixels
Display color 65536 colors
Power Adapter
Power supply 100-240 V AC 50/60Hz
Power output
1.5VDC----HDS1022M-N
9 VDC----HDS2062M-N，HDS3102M-N
Current output
1500mA----HDS1022M-N
3000mA----HDS2062M-N，HDS3102M-N
Battery type: 7.4V built-in Li-ion battery.
Working environment
Temperature
Used battery 0 to 50 °C (32 to 122 °F)
Operation
Power adapter 0 to 40 °C (32 to 104 °F)
Storage -20 to 60 °C (-4 to 140 °F)
Humidity
0 to 10 °C (32 to 50 °F) no condensation
10 to 30 °C (50 to 86 °F) 95 %
30 to 40 °C (86 to 104 °F) 75 %
Operation
40 to 50 °C (104 to 122 °F) 45 %
storage -20 to 60 °C (-4 to 140 °F) no condensation
