OWON HDS-N Series Handheld DSO & DMM 10-Appendix
Make a 50% level setting
(Typical).
Operation with the input signal frequency equal to or larger
than 50Hz.
Signal system and line/field
frequency (Video triggering mode)
Support the NTSC, PAL and SECAM broadcasting systems
of any field or line frequency.
Cymometer
Readout resolution 6 digits
AC coupling,
2Hz to full bandwidth
Frequency range
z when the triggering mode is edge triggering, it is a one
channel Cymometer.
z When the triggering mode is alternating triggering, it is
a two channel cymometer.
z When the triggering mode is video triggering，the
cymometer will not work..
Single source
Measurement
Cursor measurement Voltage difference (△V) and time difference (△T) between cursors
Peak-to-peak value, average value, root mean square value, frequency ,
period，Vmax, Vmin，Vtop, Vbase, Vamp, Overshoot, Preshoot, Rise
Time, Fall Time, +Width, -Width, +Duty, -Duty, DelayA
B and
DelayA
B .
Auto measurement
Probe
1X position 10X position
Bandwidth Up to 6 MHz (DC) Up to full bandwidth (DC)
Attenuation rate 1: 1 10: 1
Compensation range 15pf～35pf
Input resistance 1MΩ±2％ 10MΩ±2％
Input impendence 85pf～115pf 14.5pf～17.5pf
Input voltage ＜200 V DC + Peak AC ＜600 V DC + Peak AC
10.1.2 Meter
Voltage (VDC)
Input Impedance: 10MΩ.
Max. Input Voltage: 1000V (DC or AC peak-to-peak value)
Range Accuracy Resolution
400.0mv 100uV
4.000V 1mV
40.00V 10mV
400.0V 100mV
±1%±2 digits
1000.0V 1V
79
