INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 4
PL-300
Model
MUX
Type
MUX
#
MUX
WLs
#
COM
Ports
#
COM
Fiber
Type
Clients
#
MUX1
WLs
MUX2
WLs
MNG1
WL
MNG2
WL
CWDM-1M-
16W-1C-2F
CWDM 1 16 1 Dual 16 1311-
1611
N/A 1291 N/A
CWDM-2M-
4W-2C-2F
CWDM 2 4 2 Dual 8
(4+4)
1471-
1531
1471-
1531
1311 1311
CWDM-2M-
8W-2C-2F
CWDM 2 8 2 Dual 16
(8+8)
1471-
1611
1471-
1611
1311 1311
CWDM-2M-
16W-2C-2F
CWDM 2 16 2 Dual 32
(16+16)
1311-
1611
1311-
1611
1291 1291
CWDM-1M-
8W-1C-1F
CWDM 1 8 1 Single 4 1471-
1611
N/A 1291 1311
CWDM-1M-
16W-1C-1F
CWDM 1 16 1 Single 8 1311-
1611
N/A 1271 1291
CWDM-2M-
8W-2C-1F
CWDM 2 8 2 Single 8
(4+4)
1471-
1611
1471-
1611
1291 1311
CWDM-2M-
16W-2C-1F
CWDM 2 16 2 Single 16
(8+8)
1311-
1611
1311-
1611
1271 1291
1.5.1.1 CWDM MUX/DEMUX Models
1. PL-300 CWDM-1M-4W-1C-2F:
 Single passive optical MUX/DEMUX module with four wavelengths
 The MUX/DEMUX module has an additional channel for the management
OSC channel
 One COM port with dual fiber
Figure 2: PL-300 CWDM-1M-4W-1C-2F
2. PL-300 CWDM-1M-4W-1C-2F-10G:
 Single passive optical MUX/DEMUX module with four wavelengths
 The MUX/DEMUX module has an additional channel for the management
OSC channel
