INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 27
DCM Ports
NOTE: Applicable only for OADM
models.
Number of Ports Up to 4 ports
Connectors LC or SC
Physical Height 44 mm/1.733" (1U)
Width 440 mm/17.32"
Depth 230 mm/9.05"
Weight 2.4 kg/5.3 lbs
Mounting Options 19", 23", ETSI rack mountable
Environment Operating Temperature • OADM models:
0° to +70°C/+32° to +158°F
• Other models:
-20° to +85°C/-4° to +185°F
Storage Temperature -25° to +55°C/-13° to +131°F
Normal Operating
Humidity
5% to 85% RH non-condensing
Storage Humidity Up to 95% RH
Safety Standards • IEC/EN 60825-1
• IEC/EN 60825-2
• RoHS 5/6
1.6.2 CWDM MUX/DEMUX Specifications
1.6.2.1 CWDM MUX/DEMUX with Dual Fiber Specifications
Table 7: CWDM MUX/DEMUX with Dual Fiber Specifications
Parameter 4 Channels 8 Channels 16 Channels
CWDM Passband (nm) 1471-1531 1471-1611 1311-1611
Channel Spacing (nm) 20 20 20
Link Loss (MUX+DEMUX) (dB) ≤4 ≤4 ≤6
Adjacent Channel Isolation (dB) ≥30 ≥30 ≥30
Non-Adjacent Channel Isolation (dB) ≥45 ≥45 ≥45
Express Channel Wavelength (nm) 1311+/-30 1311+/-6.5 1291+/-6.5
Express Channel Link Loss (dB) ≤1.5 ≤1.5 ≤1.5
Connector Type LC/UPC LC/UPC LC/UPC
