INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 12
PL-300
Model
OADM
Type
OADM
#
OADM
WLs
#
COM
Ports
#
COM
Fiber
Type
EXP
Ports
#
EXP
Fiber
Type
Clients
#
OADM
WLs
MNG
WL
CWDM-
2O-
1Wxxxx-
2C-2F
CWDM 2 1 2 Dual 2 Dual 2
(1+1)
xxxx 1310
CWDM-
2O-
2Wxxxx-
2C-2F
CWDM 2 2 2 Dual 2 Dual 4
(2+2)
xxxx-xxxx+
20
1310
CWDM-
2O-
3Wxxxx-
2C-2F
CWDM 2 3 2 Dual 2 Dual 6
(3+3)
xxxx-xxxx+
40
1310
CWDM-
2O-
4Wxxxx-
2C-2F
CWDM 2 4 2 Dual 2 Dual 8
(4+4)
xxxx-xxxx+
60
1310
1.5.2.1 Examples of CWDM OADM Models
1. PL-300 CWDM-1O-4W1470-1C-2F:
 Single OADM module with four Add/Drop wavelengths
 The Add/Drop wavelengths are: 1470, 1490, 1510 and 1530nm
 Additional OSC 1310 management channel
 Single COM port with dual fiber
 Single express (EXP) port with dual fiber
Figure 13: PL-300 CWDM-1O-4W1470-1C-2F
2. PL-300 CWDM-1O-3W1410-2C-2F:
 Dual OADM module with three Add/Drop wavelengths
 The Add/Drop wavelengths are: 1410, 1430 and 1450nm
