Appendix C: PL-300 Fiber Shelf
This appendix describes the PL-300 fiber shelf.
In this Appendix
Fiber Shelf ........................................................................................... 51
C.1 Fiber Shelf
The fiber shelf is an optional tray that can be attached to the PL-300 to help you
organize the optical fibers.
The following figure illustrates the mechanical details of the fiber shelf.
Figure 38: Fiber Shelf Diagram
